Name: 24000 BTU Parilla AC Unit Non-inverter Home Air Conditioners heating and cooling System
Brand: PARILLA HVAC
SKU: PRL-SP-24K-CH(No-Off)
Price: 366.00 USD
Availability: InStock

24000 BTU Parilla AC Unit Non-inverter Home Air Conditioners heating and cooling System

$366.00Unit

Parilla split wall-mounted air conditioner, only the cooling version, uses environmentally friendly refrigerants R32 or R410a, suitable for the global market. The cooling capacity ranges from 9000 BTU to 24000 BTU in 4 standard versions. The factory also supports customizations for high-power versions of 30000 BTU and 36000 BTU.

Add to quote

SKU: PRL-SP-24K-CH(No-Off) Category: Air Conditioners

16+ Years

Research and development manufacturing experience

Parilla Specialising in air purification technology and the design and manufacture of air cooling and heating equipment for 16 years, supporting OEM/ODM partnerships.

Cleanroom Equipument,Clean Air Handling Equipment, Air Conditioner,Humidifier,Dehumidifier,Heating and cooling equipment Dehumidifier

40000㎡

Production area

250+

Professional manufacturing team

30+

Professional manufacturing team

60+

Popular countries and regions

Comprechensive OEM/ODM Service

We have successfully cooperated with many brands and customized

ODM OR OEM

Professional manufacturing
Air handling units and HVAC equipment

Split Air Conditioner

Parameter Split Air Conditioner Parameter

FIXED FREQUENCY			SP/G26CH	SP/G35CH	SP/G50CH	SP/G70CH
Rated Power supply			1Ph / 220-240V/50Hz	1Ph / 220-240V/50Hz	1Ph / 220-240V/50Hz	1Ph / 220-240V/50Hz
Workable Power supply			1Ph / 185-260V/50Hz	1Ph / 185-260V/50Hz	1Ph / 185-260V/50Hz	1Ph / 185-260V/50Hz
Cooling		Capacity (btu/h)	9000	12000	18000	24000
		Capacity (W)	2500	3200	4800	6500
		Input (W)	900	1160	1690	2300
		Rated current (A)	4.10	5.30	7.80	10.70
		EER	2.78	2.76	2.84	2.83
Heating		Capacity (btu/h)	9000	12000	18000	24000
		Capacity (W)	2500	3200	4800	6500
		Input (W)	900	1160	1690	2300
		Rated current (A)	4.10	5.30	7.80	10.70
		COP	2.78	2.76	2.84	2.83
Max. input consumption (W)			1300	1750	2500	3000
Max. current (A)			5.8	7.9	11.6	13.9
Compressor		Type	Rotary	Rotary	Rotary	Rotary
		Brand	GMCC,GREE	GMCC,GREE	GMCC,GREE	GMCC,GREE，HIGHLY
Indoor unit	Indoor Coil	Fin material	Golden& hydrophili	Golden& hydrophili	Golden& hydrophili	Golden& hydrophili
		Tube outside dia.and material	φ7mm, Inner Grooved	φ7mm, Inner Grooved	φ7mm, Inner Grooved	φ7mm, Inner Grooved
	Indoor air flow (Turbo/Hi/Mi/Lo) (M3/h)		500/450/370/320	550/450/370/320	850/750/650/580	1050/950/800/680
	Rated input Power(cooling/heating) (W)		10	13	35	45
	Rated current (cooling/heating) (A)		0.2	0.2	0.35	0.4
	Moisture Removal (KG/h)		0.8	1.1	2	2.6
	Noise level(Turbo/Hi/Mi/Lo) (dB(A))		39/34/32/30	40/35/32/30	45/42/39/37	49/47/45/42
	Unit dimension (WHD)		695×275×190	780×275×190	910×295×205	1075×330×240
	Packing (WHD)		763×322×241	847×322×241	975×340×255	1146×412×318
	Net weight (KGs)		6	6.5	9	14
	Gross weight (KGs)		8	8.5	11	18
Outdoor unit	Outdoor coil	Fin material	Golden& hydrophilic	Golden& hydrophilic	Golden& hydrophilic	Golden& hydrophilic
		Tube outside dia.and material	φ5mm, Inner Grooved	φ5mm, Inner Grooved	φ5mm, Inner Grooved	φ7mm, Inner Grooved
	Noise level (dB)		50	52	55	59
	Unit dimension (WHD) (mm)		610×295×495	710×295×495	730×305×550	780×350×600
	Packing (WHD) (mm)		704×324×530	818×328×530	835×340×580	896×387×625
	Net weight (KGs)		19	23	30	37
	Gross weight (KGs)		22	26	33	41
	Refrigerant type		R410A	R410A	R410A	R410A
Refrigerant pipe		Liquid side (mm)	Φ6	Φ6	Φ6	Φ6
		Gas side (mm)	Φ9	Φ9	Φ12	Φ12
		Max. refrigerant pipe length (m)	10	10	10	15
		Max. difference in level (m)	5	5	5	10
Operation temperature range			-7℃-43℃	-7℃-43℃	-7℃-43℃	-7℃-43℃
Ambient temperature range			-7℃-48℃	-7℃-48℃	-7℃-48℃	-7℃-48℃
Application area (MM2)			10~17	13~27	20～40	30～55
Sets per 40ft HQ/20ft			360/167	334/143	280/133	186/78

Brand

PARILLA HVAC

Cooling Capacity

9000 BTU / 0.75Ton / 1Hp

Maximum input power(W)

3000W

Rated Power supply

1Ph / 220-240V/50Hz

Click to enlarge

Back to products

Compare

Add to wishlist

Description

FIXED FREQUENCY			SP/G26CH	SP/G35CH	SP/G50CH	SP/G70CH
Rated Power supply			1Ph / 220-240V/50Hz	1Ph / 220-240V/50Hz	1Ph / 220-240V/50Hz	1Ph / 220-240V/50Hz
Workable Power supply			1Ph / 185-260V/50Hz	1Ph / 185-260V/50Hz	1Ph / 185-260V/50Hz	1Ph / 185-260V/50Hz
Cooling		Capacity (btu/h)	9000	12000	18000	24000
		Capacity (W)	2500	3200	4800	6500
		Input (W)	900	1160	1690	2300
		Rated current (A)	4.10	5.30	7.80	10.70
		EER	2.78	2.76	2.84	2.83
Heating		Capacity (btu/h)	9000	12000	18000	24000
		Capacity (W)	2500	3200	4800	6500
		Input (W)	900	1160	1690	2300
		Rated current (A)	4.10	5.30	7.80	10.70
		COP	2.78	2.76	2.84	2.83
Max. input consumption (W)			1300	1750	2500	3000
Max. current (A)			5.8	7.9	11.6	13.9
Compressor		Type	Rotary	Rotary	Rotary	Rotary
		Brand	GMCC,GREE	GMCC,GREE	GMCC,GREE	GMCC,GREE，HIGHLY
Indoor unit	Indoor Coil	Fin material	Golden& hydrophili	Golden& hydrophili	Golden& hydrophili	Golden& hydrophili
		Tube outside dia.and material	φ7mm, Inner Grooved	φ7mm, Inner Grooved	φ7mm, Inner Grooved	φ7mm, Inner Grooved
	Indoor air flow (Turbo/Hi/Mi/Lo) (M3/h)		500/450/370/320	550/450/370/320	850/750/650/580	1050/950/800/680
	Rated input Power(cooling/heating) (W)		10	13	35	45
	Rated current (cooling/heating) (A)		0.2	0.2	0.35	0.4
	Moisture Removal (KG/h)		0.8	1.1	2	2.6
	Noise level(Turbo/Hi/Mi/Lo) (dB(A))		39/34/32/30	40/35/32/30	45/42/39/37	49/47/45/42
	Unit dimension (WHD)		695×275×190	780×275×190	910×295×205	1075×330×240
	Packing (WHD)		763×322×241	847×322×241	975×340×255	1146×412×318
	Net weight (KGs)		6	6.5	9	14
	Gross weight (KGs)		8	8.5	11	18
Outdoor unit	Outdoor coil	Fin material	Golden& hydrophilic	Golden& hydrophilic	Golden& hydrophilic	Golden& hydrophilic
		Tube outside dia.and material	φ5mm, Inner Grooved	φ5mm, Inner Grooved	φ5mm, Inner Grooved	φ7mm, Inner Grooved
	Noise level (dB)		50	52	55	59
	Unit dimension (WHD) (mm)		610×295×495	710×295×495	730×305×550	780×350×600
	Packing (WHD) (mm)		704×324×530	818×328×530	835×340×580	896×387×625
	Net weight (KGs)		19	23	30	37
	Gross weight (KGs)		22	26	33	41
	Refrigerant type		R410A	R410A	R410A	R410A
Refrigerant pipe		Liquid side (mm)	Φ6	Φ6	Φ6	Φ6
		Gas side (mm)	Φ9	Φ9	Φ12	Φ12
		Max. refrigerant pipe length (m)	10	10	10	15
		Max. difference in level (m)	5	5	5	10
Operation temperature range			-7℃-43℃	-7℃-43℃	-7℃-43℃	-7℃-43℃
Ambient temperature range			-7℃-48℃	-7℃-48℃	-7℃-48℃	-7℃-48℃
Application area (MM2)			10~17	13~27	20～40	30～55
Sets per 40ft HQ/20ft			360/167	334/143	280/133	186/78

Additional information

Brand	PARILLA HVAC
Cooling Capacity	9000 BTU / 0.75Ton / 1Hp
Maximum input power(W)	3000W
Rated Power supply	1Ph / 220-240V/50Hz
